Canyao CY-900SQ Remote Multi-function Crawler Mower 28HP Twin Cylinder Complete Set Export

Name: Canyao CY-900SQ Remote Multi-function Crawler Mower 28HP Twin Cylinder Complete Set Export
Brand: GLOBALMACHEX
Availability: InStock
Rating: 5 (1 reviews)

Full complete set of Canyao CY-900SQ twin-cylinder high-power remote multi-function crawler machine. Equipped with Loncin 764 twin-cylinder 28HP diesel engine, hybrid oil-electric dual 800W drive motors. Canyao 4.0 electronic control system supports full-function remote control up to 500 meters. 4-in-1 functions: mowing, pesticide spraying, cargo transport, dozing & snow removal. Crawler chassis realizes 360° in-place tank rotation, max climbing angle 35°. 8mm thick integrated welded frame, dual-circuit overload protection with human-machine separation design, 900mm wide 65Mn steel cutting width. Modular design for easy maintenance, full machine supplied with all wearable spare parts, bilingual manual and full export documents as one set.

$2370.00 - 2607.00

发送消息联系供应商

山东灿耀智慧农业装备有限公司

Main Products: 农机, 农机配件

查看供应商

成立年份 2024 年成立

主营产品农机, 农机配件

员工人数 50 人以下

工厂面积 1,000-5,000 m²

年销售额 100 万 - 500 万美元

主营市场东南亚

产品详情

产品规格

贸易信息

Canyao 4.0 intelligent electronic control system supports 500m long-distance wireless remote control for full operations including start-stop, lifting, throttle, mowing and spraying. 48V stabilized circuit with relay overload protection delivers stable & precise control, leading solution in agriculture machinery industry.
The frame is integrally welded with 8mm thick Q235 steel plate, 5mm plate for attachments and 2mm plate for outer shell. Mortise-and-tenon reinforcing ribs provide strong load-bearing capacity. The whole machine undergoes sand blasting rust removal and high-temperature plastic spraying for outstanding rust, corrosion and weather resistance, low gravity center ensures excellent climbing performance.
Matched with DJ series track-specific planetary reduction gearbox and hybrid oil-electric dual motor drive, it supports forward/reverse movement, left/right turning and 360° tank-style in-place rotation, compact body fits narrow-row fruit orchards.
Dual-circuit current overload protection with human-machine separation design, dual emergency stop of main circuit and remote controller, one-click shutdown under equipment faults to greatly improve safety factor during operation on mountains and steep slopes.
Modular standardized spare parts design with simple user-friendly operation interface, operators master independent operation after half-hour training. Full maintenance tools delivered with machine, daily maintenance only requires simple wrenches to cut long-term service cost.
Low crawler chassis with 0-30cm remote adjustable ground clearance, in-place rotation fits short fruit trees, capable of climbing max 35° slopes, suitable for apple, peach, vine orchards, photovoltaic wasteland and greenhouses with complex terrain.
All hardware and software of the whole machine are independently developed with complete trademarks and patent IP rights. All motors, crawlers and twin-cylinder engine adopt top national standard brand accessories, the whole machine has passed 500-hour uninterrupted extreme durability test.
28HP high-displacement Loncin twin-cylinder engine with abundant torque reserve, no power stall under heavy climbing load. 900mm wide thick manganese steel blades are wear-resistant and impact-resistant for clean weeding without residual grass.
Expandable 4-in-1 multi-function design, optional wind spray system, cargo transport and snow/soil dozer, one machine replaces multiple farm equipment to reduce farm procurement cost.
Complete machine integrated packing delivery, main unit, full wearable spare parts and qualification documents all included in one set, one-stop supporting service including container reinforcement, customs clearance and certificate of origin agency.

Machine Model

CY900SQ, Dual 48V Nanpu 800W Motors

Main Power

Loncin 764 Twin Cylinder, 28 HP

Drive Gearbox

WDJO5 Track Planetary Gearbox, Ratio 31.36 Two-stage

Start Mode

Remote + Manual Start, Max Remote Range 500 Meters

Mowing Kit

2 sets 65Mn Steel Blades, 6mm Thick, 900mm Width

DC Generator

48V 2500W, 80A

Crawler Track

Jinlilong 180/60/50, Width 18cm

Traction Battery

48V20Ah for machine driving

Engine Battery

12V55Ah for engine electric start

Lift Clearance

Remote adjustable, Max 30cm

Remote Controller

C7 MINIplus, Max 500 Meters

Travel Speed

6-8km/h

Max Climbing Slope

≤35°

Overall Size & Net Weight

1800×1400×940mm, 494kg

Fumigated Wooden Case

1900×1450×1060mm, 554kg

起订量

1 件

Description

Canyao 4.0 intelligent electronic control system supports 500m long-distance wireless remote control for full operations including start-stop, lifting, throttle, mowing and spraying. 48V stabilized circuit with relay overload protection delivers stable & precise control, leading solution in agriculture machinery industry.
The frame is integrally welded with 8mm thick Q235 steel plate, 5mm plate for attachments and 2mm plate for outer shell. Mortise-and-tenon reinforcing ribs provide strong load-bearing capacity. The whole machine undergoes sand blasting rust removal and high-temperature plastic spraying for outstanding rust, corrosion and weather resistance, low gravity center ensures excellent climbing performance.
Matched with DJ series track-specific planetary reduction gearbox and hybrid oil-electric dual motor drive, it supports forward/reverse movement, left/right turning and 360° tank-style in-place rotation, compact body fits narrow-row fruit orchards.
Dual-circuit current overload protection with human-machine separation design, dual emergency stop of main circuit and remote controller, one-click shutdown under equipment faults to greatly improve safety factor during operation on mountains and steep slopes.
Modular standardized spare parts design with simple user-friendly operation interface, operators master independent operation after half-hour training. Full maintenance tools delivered with machine, daily maintenance only requires simple wrenches to cut long-term service cost.
Low crawler chassis with 0-30cm remote adjustable ground clearance, in-place rotation fits short fruit trees, capable of climbing max 35° slopes, suitable for apple, peach, vine orchards, photovoltaic wasteland and greenhouses with complex terrain.
All hardware and software of the whole machine are independently developed with complete trademarks and patent IP rights. All motors, crawlers and twin-cylinder engine adopt top national standard brand accessories, the whole machine has passed 500-hour uninterrupted extreme durability test.
28HP high-displacement Loncin twin-cylinder engine with abundant torque reserve, no power stall under heavy climbing load. 900mm wide thick manganese steel blades are wear-resistant and impact-resistant for clean weeding without residual grass.
Expandable 4-in-1 multi-function design, optional wind spray system, cargo transport and snow/soil dozer, one machine replaces multiple farm equipment to reduce farm procurement cost.
Complete machine integrated packing delivery, main unit, full wearable spare parts and qualification documents all included in one set, one-stop supporting service including container reinforcement, customs clearance and certificate of origin agency.
